Tube Tuggers
Tube Tugger
Semi-Continuous Hydraulic Tube Pulling System
Elliott’s Tube Tugger is a powerful continuous hydraulic tube pulling system for removing any type of tube material effortlessly from heat exchangers, chillers, and other heat transfer vessels.
-
Tube Size: 0.625” to 1.250” (15.9 – 31.8mm) OD
-
Type: Tube Puller
-
Application: Heat exchangers, chillers, and other heat transfer vessels
-
Pulling Capacity: 30 Ton (27Mt)
-
Stroke: 3" (76.2mm)
Super Tube Tugger
Semi-Continuous Hydraulic Tube Pulling System
Elliott’s Super Tube Tugger is a powerful continuous hydraulic tube pulling system for removing any type of tube material effortlessly from boilers and surface condensers.
-
Tube Size: 1.500” to 2.000” (38.1 – 50.8mm) OD
-
Type: Tube Puller
-
Application: Boilers and Surface Condensers
-
Pulling Capacity: 60 Ton
-
Stroke: 4" (101mm)
