Elliott's 430G Pneumatic Hammer is the recommended driving tool for Elliott's Beading Tools and Flaring Tools.

Beading Tools are made with different size radii for beading tubes in firetube boilers while Flaring Tools are used for flaring the inside of tube ends.

The 430G Pneumatic Hammer accepts Type No. 6 0.680” (17.3mm) diameter by 2-3/8” (60.3mm) long shanks.

Features & Benefits:

• Lightweight & compact design – easy to move in tight areas.
• Uses retainers on tools – improved operator safety.

Specifications

• Piston Diameter & Stroke: 1-1/8” X 2” (28.6 X 50.8mm)
• Length (Overall): 14” (355.6mm)
• Blows per minute: 2,300
• Net Weight: 17 lbs. (7 Kg.)
• Air Requirement: 30 CFM @ 90 PSI
• Hose Diameter: 1/2” (12.7mm)
