Elliott's Rental Model RX709600P Manhole Seat Grinder is the answer to on-site resurfacing of boiler manway holes. Pitted gasket areas are easily resurfaced and put into first class condition in minutes!

Elliott offers three different grit of grinding wheels. The fine grit (60 grit) grinding wheel is the preferred wheel ”“ in most cases this wheel will accommodate all resurfacing applications. Only in cases where pitting or warpage is extreme, the coarse grit (36 grit) grinding wheel is recommended. The coarse wheel should only be used to bring the seat back close to the finished tolerance. Final cut passes of the manway seat should be accomplished with the fine grit grinding wheel. Finally, to remove excess weld or weld splatter, the weld removal (24 grit) grinding wheel is recommended.

Features & Benefits:

• Saves lots of time as the boiler does not need to be brought up in order to check for leaks.
• Pitted gasket areas are easily resurfaced and put into first class condition in minutes.
• Universal size fits many different applications.
• Coarse grinding wheels available for quick removal of material. Fine grinding wheels available for smooth finish.

Specifications

• Accommodates manways having minimum elliptical of 10” x 14” (254.0 x 355.6mm) and maximum of 14” x 18” (355.6 x 457.2mm).
• RPM: 6,000 @ 90 PSI.
• Weight: 92 Lbs (13.6 kgs).
